type Oxidative drying poly Ester Polyurethane Dispersion
Supply Form in a ratio of 53.5:1.5 About 45% in water and neutralizer ethyldiisopropylamine (EDIPA)
Purpose
For the preparation of water-based air-drying and forced-drying with good corrosion resistance high-gloss paint and primer. Mainly used in general industrial finishing paint.
Products Specifications
Features | Number | Units of measure | Test method |
acid value | about 12 | mg KOH/g | DIN ISO 3682 |
Viscosity, 23 °C (D is about 40 s-1) |
about 300 | mPa·s | DIN EN ISO 3219/A.3 |
Non-volatile components (1g/1h/125°C, convection oven) |
about 45 | % | DIN EN ISO 3251 |
pH (1:4 in demineralized water) |
about 7.2 | DIN 53 785 |
Other Value
Features | Number | unit of measure | Test method |
average particle size (Photon Correlation Spectroscopy) |
about 125 | nm | |
Supply Form Appearance | emulsion, cloudy | ||
density, 20°C | about 1.0 | g/ml | DIN 53 217/3 |
Phase Capacitance
Can be mixed with other water-based bases, but should be tested each time for compatibility sex. All standard inert and basic pigments can be used in paint formulations based on Bayhydrol XP 2592.
Features
Bayhydrol XP 2592 (development name: BHB 13124) does not contain any co-solvents, Skinning agent as well as desiccant, therefore not marked. Coatings based on this resin dry quickly and have a fairly high hardness after drying.
After one night curing, it has good water resistance. However, high-gloss coatings require a certain amount of suitable co-solvents and added amines in the formulation.
Primers based on Bayhydrol XP 2592 show excellent corrosion protection.
Apply
Bayhydrol XP 2592 is a universal Resin; due to its excellent corrosion protection properties, it can also be used as a raw material for primers and monocoats.
Bayhydrol XP 2592 is very shear stable and is therefore recommended for dip coating applications.
Processing
Bayhydrol XP 2592 is supplied without co-solvent and uses ethyldiisopropylamine Neutralize to about 60%. For better pigment wetting, it is recommended to increase the amount of amine (ethyldiisopropylamine, triethylamine or dimethylethanolamine in case of forced drying). Added amines should be added to the mill base with the aim of achieving a neutralization level of 80-100%, depending on the coloration.
The addition of amines causes a significant increase in viscosity.
The organic co-solvent added to the formulation will affect the film formation, gloss and drying properties: add 4% of 2-butoxyethanol/Dowanol DPnb mixture at a ratio of 1:1,
The resulting coatings had similar properties to coatings based on Bayhydrol VP LS 2917 resin.
Please adopt other handling and formulation recommendations from the original formulation.
dry Agent
All existing water-based desiccants can be used, such as Nuodex® Co 7 aqua (0.08% cobalt, calculated on solid resin). Even cobalt-free driers can be used: comparable results can be achieved with Borchers® Dry VP 0347 (3-5% supply form, calculated on solid resin).
anti Skinning agent
Recommended as follows:
Anti-skinning agent based on MEK: such as Borchinox® M2 (0.3%, calculated on solid resin) or anti-skinning agent without MEK: such as Ascinin® Anti Skin 0445 (0.25%, calculated on solid resin)
Save
Store in an airtight container at a temperature between +5°C and +23°C , under these conditions, the product is stable for at least 6 months.
The product freezes below 0°C and may be destroyed. Therefore, product storage should avoid frost hazard.
Security
Hazard Identification
This product is not classified as dangerous according to European Commission Directive 67/548/EEC or 1999/45/EC.
The safety data sheet (525263) must be observed, which includes information on labeling, transport and storage, as well as information on product use, product safety and ecology.
Note
This product is experimental and we do not yet have extensive experience with it. Therefore, the company does not make any guarantees about the performance of the product in operation and use.
