type polyester/polyester Acrylate Dispersion
Supply Form in proportion to approx. 48.9:8:1.1 in water/2-butoxyethanol and neutralizer dimethylethanolamine about 42%
Purpose
For the preparation of industrial baking varnishes, which have high whiteness when exposed to high temperature degree of retention. It can also be used to prepare two-component polyurethane primers and topcoats for plastics.
Products Specifications
| Features | Number | Units of measure | Test method |
| acid value | about 8 | mg KOH/g | DIN EN ISO 2114 |
| Viscosity, 23 °C (D about 40 S－1) |
about 1500 | mPa·s | DIN EN ISO 3219/A.3 |
| Non-volatile components (1g/1h/125°C) |
about 42 | % | DIN EN ISO 3251 |
|
pH (1:4 in demineralized water) |
about 8.0 | DIN ISO 976 |
Other Data
| Features | value | unit of measure | Test method |
| Hydroxyl content, solvent free | about 3.8 | % | DIN 53 240 |
| average particle size (Photon Correlation Spectroscopy) |
<150 | nm | |
| Minimum film forming temperature (MFT) |
<0 | °C | DIN ISO 2115 |
| density, 20°C | about 1.06 | g/ml | DIN EN ISO 2811 |
| Flashpoint | >98 | °C | DIN EN ISO 2719 |
dissolve Sexuality/Dilution
Bayhydrol® VP LS 2227/1 can be diluted in water. It can be miscible with glycol ether and glycol ether ester in a certain proportion.
Phase Capacitance
Suitable industrial baking varnish co-reactants are: hexamethoxymethylmelamine resin, Partially etherified melamine resins such as Maprenal® MF 904 and 915, Cymel® 303, 325 and 327, water-based aliphatic polyisocyanates such as Bayhydur® BL 5140 and BL 5235.
We recommend using Bayhydur® VP LS 2306 and Bayhydur 3100 as co-reactants when preparing primers and topcoats for plastics.
Features /application
The viscosity of the product is largely dependent on the pH. During storage, the pH may drop, as may viscosity. Adding a small amount of 10% aqueous dimethylethanolamine solution can restore the viscosity to its original value.
Industrial paint:
For optimum pigment wetting, the pH can be adjusted to 8.5 to 9 with a 10% aqueous solution of dimethylethanolamine. Details can be obtained from the associated recommended formulations.
Bayhydrol VP LS 2227/1 is blended with melamine resins for the preparation of baking topcoats with a co-solvent content of less than 5% at the application viscosity. The paint was dried at 120°C for 30 minutes. The ratio of Bayhydrol VP LS 2227/1 to amino resin (calculated on resin solids) is 80:20. There are many different amino resins available on the market, but compatibility should be tested first.
Since the product contains hydroxyl groups, it can also be used as a co-reactant for waterborne aliphatic polyisocyanates such as Bayhydur BL 5140 and BL 5235. The ratio of OH to NCO should be 1:1.
In order to achieve good storage stability of coatings containing Bayhydrol VP LS 2227/1, the pH of the coating should be adjusted between 8.5 and 9 after preparation.
Coatings for plastics:
For coatings on plastics we recommend Bayhydrol VP LS 2306 and/or Bayhydur 3100. The ratio of OH to NCO should be 1:1.5.
Bayhydrol VP LS 2227/1 has good pigment wetting and high shear stability. Ball mills and sand mills are suitable grinding equipment. Even grinding temperatures of 50°C do not have a negative effect on the quality of the paint.
Since there are many different pigments to choose from, their storage stability should be tested. Kerr-McGee's rutile titanium dioxide pigments, especially Tronox® R-KB-4, are particularly suitable.
Cleaning Preparation and construction equipment Can be cleaned with water, alkaline cleaner or isopropyl alcohol
Save
This product does not contain fungicides.
Stored between 5°C and 23°C in an airtight container, this product is stable for at least 6 months.
The product freezes at 0°C and may be destroyed. Therefore, product storage should avoid frost hazard.
Security
Hazard Identification
This product is not classified as dangerous according to European Commission Directive 67/548/EEC or 1999/45/EC.
1-Butoxyethanol that penetrates the skin can be hazardous.
The Safety Data Sheet (304232) must be observed which includes information on labelling, transport and storage as well as product handling, product safety and ecology.
Note
This product is experimental and we do not yet have extensive experience with it. Therefore, the company does not make any guarantees about the performance of the product in operation and use.
