Products Description
Model SPW-1901
Type Water-based polyurethane glue
Application Suitable for cladding and vacuum forming of automotive interior parts, including door panels, Armrest board, instrument panel, central control armrest, seat back panel, etc.
The substrates used include ABS, PC, PVC, wood-plastic board, fiberboard and processed Treated PP/PE, etc.
Performance Low activation temperature and good heat resistance
No irritating odor, environmentally friendly
Technology Parameters
Item |
typical data |
Appearance |
white lotion |
Viscosity (25℃/6rpm/S2) |
about 3500mPa.s |
solid content |
about 49% |
Curing agent (SPW-1900) |
Isocyanate curing agent, colorless transparent liquid (color adjustable), Adding ratio 5%-7% |
Construction Conditions
Item |
typical data |
Using temperature |
10-35℃ |
Amount of glue spray on one side |
60-100g/m2 |
Operation time after mixing |
8-12h (curing agent addition 5%-7%) |
Drying temperature |
≤70℃ |
Opening time (after drying) |
2-3h |
Activation temperature (coating) |
≥50℃ |
Activation temperature (vacuum forming) |
≥100℃ |
pressing time |
30s-2min |
Time to reach maximum strength |
72h |
Operation Tip
1. Mix the main agent and curing agent evenly by weight before use;
2. Before spraying glue, the surface of the substrate must be dry, clean, dust-free and oil-free;
3. Spraying at room temperature, single-sided or double-sided spraying with a spray gun; Surface spraying requires a functional test in advance;
4. Pressing or vacuum forming can only be done after drying;
5. The longer the waiting time after drying, the higher the activation temperature.
Packaging
20kg/plastic drum, 1kg/can (curing agent)
data Basics
All the data expressed in the product data sheet are obtained in laboratory tests . Actual measurements may vary due to circumstances beyond our control.
Important Description
For information and advice on transportation, handling, storage and disposal of chemicals, users Reference should be made to the actual Safety Data Sheet, which includes physical, ecological, toxicological and other safety-related data.
Legal Disclaimer
When the product is properly stored, handled and applied under normal conditions, Haoyi The information provided by New Material Company and the construction treatment suggestions given according to the actual situation are based on Haoyi New Material Company's good confidence in its current knowledge and experience. In actual application, due to the difference of materials, substrates and actual site conditions, it cannot be inferred from the information here or any written recommendation or any other suggestion that Haoyi New Material Co., Ltd.’s commerciality and support for its products Makes no warranties and assumes no liability of fitness for a particular purpose. Users of the product should test the suitability of the product for their application and intended use. Haoyi New Material Company reserves the right to change the nature of its products. The use rights of third parties shall be respected. All orders are subject to current sales and shipping terms. Users should refer to the latest version of relevant product manuals, which can be provided by Haoyi New Material Company upon request.
