Product Introduction
Van Truus Specialty Products offers a new line of castor oil derived, low cost, 100% solids polyurethane polyols.
These new polyols are named POLYCIN® D, T and M series. These hydroxyl-terminated ricinoleate derivatives react with standard chemical isocyanates to form urethanes for coatings, adhesives, sealants, elastomers (CASE).
Product Features
Excellent electrical properties, low vapor hazard, easy handling, low viscosity, excellent permeability, room temperature curing, anti-reversion properties, thermal stability;
Low heat release, low stress, low temperature resistance, excellent moisture retention, low cost, 100% solid content, no volatile organic compounds (VOC)
Hydrolytic stability
The polyurethane system synthesized with POLYCINS® exhibits very good moisture and heat aging resistance under any conditions. For example, POLYCINS®-based systems not only passed but exceeded the requirements of the Navy's avionics test at 95% relative humidity and 100°C for 28 days.
Low heat release
Electronic components such as toroidal coils, reeds, mercury switches, inductors, and selenium rectifiers are sensitive to stress caused by packaging materials, which may cause performance changes and even damage components . The thermal sensitivity of electronic components and the avoidance of mechanical deformation require low heat dissipation. Polyurethane systems synthesized with POLYCINS® meet the requirement for low exotherm at temperatures averaging 85°F (29.4°C) above ambient.
Minimal shrinkage
Room temperature curing POLYCIN® elastomers show little or no shrinkage. This maintains the performance integrity of the finished system or product.
Temperature stability
Test data show that POLYCIN® elastomer has remarkable thermal stability. Therefore, they guarantee a wide operating temperature range with a maximum interval temperature of 150°C.
· Chemical and solvent resistance
The volume resistivity of the POLYCIN® system did not change after 6 months of contact with seawater. Immersing POLYCIN® elastomers in 10% hydrochloric acid and sodium hydroxide solutions for 7 days is completely unaffected.
The POLYCIN® system has excellent solvent resistance to aliphatic products (petroleum, heptane) and hydroxyl-containing materials (ethylene glycol). After soaking at room temperature for 7 days, there was little or no change in their linear dimensions. However, when using aromatic solvents (xylene), oxygenated solvents (acetone), and chlorinated solvents (tetrachloroethylene), some linear expansion may occur after 3 hours at room temperature.
Reactive thinner
POLYCINS® provides an excellent means for reducing volatile organic compounds (VOC) and reducing viscosity in polyurethane resin systems. At the same time, it also has performance in improving hardness, elasticity, gloss, fluidity and wettability.
Security and Handling
POLYCINS® is non-toxic, biodegradable, and produced from renewable resources. Under normal storage conditions, its shelf life is at least two years.
Physical Properties </st
2 2 2 2 Coating performance Physical Test DB®0il D-120 D-140 D-265 D-290 T-400 M-280 M-365 7-day pencil hardness 2B — HB 2B HB H HB HB Direct Impact, 140 lbs Pass — Pass Pass Pass Pass Pass Pass Reverse Shock, 140 lbs Pass — Pass Pass Pass Pass 120 Pass 200 butanone twice rub Pass — Pass Pass Pass Pass Pass Pass Sodium hydroxide 50% P — P P P P P P Toluene F — P P P P P P Acetic acid F — F F F F F F brake fluid F — P P F P P P water P — P P P P P P Note: NCO:OH=1.05:1.0HDT P=Pass F=Fail Adhesives, Sealants, and Elastomers (ASE) Properties Physical Test DB®0il D-120 D-140 D-265 D-290 T-400 Shore A hardness 75 41 45 100 100 100 Shore D hardness 25 — 14 70 74 81 Stretchability, psi 495 113 225 3200 4650 7600 Elongation, % 80 60 185 135 200 15 Physical Test M-280 M-365 D1000 D2000 D3000 D4000 Shore A Hardness 100 100 42 16 16 15 Shore D hardness 77 82 Stretchability, psi 5750 8100 150 40 39 43 Elongation, % 20 10 70 75 70 65 Note: MDI is cured at NCO/OH=1.05/1.0 Elongation, % 80 60 185 135 200 15 Physical Test M-280 M-365 D1000 D2000 D3000 D4000 Shore A Hardness 100 100 42 16 16 15 Shore D hardness 77 82 Stretchability, psi 5750 8100 150 40 39 43 Elongation, % 20 10 70 75 70 65 Note: MDI is cured at NCO/OH=1.05/1.0
